ROTEL T11 FM/DAB+ Tuner (Silver)

Description

T11

Rotel has been producing quality tuners since the 1960s. One of the latest additions to this long-established line-up is the T11 FM/DAB+ tuner. It provides a wealth of listening options with easy access to classic analogue FM stations as well as newer DAB+ (Digital Audio Broadcasting) services.

Like the T14, T11 features the ability to easily store and recall up to 30 presets each for FM or DAB+ stations. A further useful feature common to all 14 Series products is the ability to dim the display panel and power LED to provide a comfortable visual reference in all lighting environments.

Dimensions (W × H × D)

430 × 73 × 330mm
17″ × 2.9″ × 13″

Front Panel Height

60mm (2.36″)

Power Requirements

120V, 60Hz

Power Consumption

10W

Standby Power Consumption

<0.5W

Net Weight

4.3kg (9lbs.)

BTU Rating

17 BTU/h

DAB Sensitivity

-80dBm

DAB Tuning Range

Band III (174-240MHz)

DAB Audio Date Rate

224Kbps Max

DAB Frequency Response

20Hz – 20kHz ±1dB

DAB Analog Output

2.1V at 0dBfs

DAB Antenna Input

75Ω F Connector

FM Usable Sensitivity

22.2dBf

FM 50dB Quieting Sensitivity

27.2dBf (Mono)

FM Signal to Noise Ratio (at 65dBf)

63dBf (Mono)

60dBf (Stereo)

FM Harmonic Distortion (at 65dBf)

0.2% (Mono)

0.3% (Stereo)

FM Frequency Response

10Hz – 15kHz ±3dB

FM Stereo Separation (100Hz/1kHz)

40dB/37dB

FM Output Level

1V

FM Antenna Input

75Ω F Connector
