Description
concept mc Signature
Reduce to the maximum
The concept mc Signature combines high-quality moving coil technology with a minimalist design.
Here, audiophile explorers discover what the optimization of magnetic circuits can deliver: This cartridge releases crystal clear sounds and represents nothing less than a revolution in it‘s class.
Equipped with a boron cantilever, the concept mc Signature has channel matching to within half a decibel, 11 ohms internal impedance and is fitted with a Micro line stylus – features normally unheard of in this price range.
All of which adds up to make this high-quality cartridge a bargain for the cost-conscious high-end fan.
| Total mass: | 8.0g |
| Frequency response: | 20Hz – 20kHz |
| Output voltage (at 5 cm/sec): | 0.4mV |
| Channel separation: | > 30dB |
| Channel balance: | < 0.3dB |
| Tracking ability: | 80μm |
| Recommended tracking force: | 2.2g (± 0.2g) |
| Cartridge impedance: | 11Ω |
| Cantilever / stylus shape: | Boron / Micro Line |
| Compliance: | 9μ/mN |
| Coil assembly: | — |
| Coil material | OFC – copper |
| Cartridge body: | Aluminum-magnesium alloy with ceramic surface layer |
